USB AVRISP XPII, AVR Programmer

USB AVRISP XPII, AVR Programmer

Momenteel niet op voorraad, bestel als pre-order. Geschatte leverdatum 08-04-2024 - 09-04-2024.
€ 49,95 € 41,28
Ontvang bij aankoop
minimaal 24 SOS spaarpunten
(t.w.v. €2,40)i
Niet op voorraad
Bestel als pre-order en ontvang het artikel wanneer het weer op voorraad is.

USB AVRISP XPII, AVR Programmer



https://www.waveshare.com/wiki/USB_AVRISP_XPII

https://www.waveshare.com/usb-avrisp-xpii.htm


Meer informatie
Artikelnummer A00401
Merk Waveshare
Fabrikantcode 302
Garantie 2 Jaar
Gewicht 0.161 kg
Aansluitingen

AT AVRISP mkII compliant
- Compatible with AT AVR ISP, easy to use, stable and reliable

Based on AT AVRISP mkII firmware
- Identified as AVRISP mkII in AVRStudio, high speed programming

Upgradable firmware
- Firmware is upgradable to Support Future Devices
- Automatic Upgrade

Supported software
- AVR Studio 4/5/6 or WINAVR(GCC) is used as front-end software
- Supports the program files generated by IAR, ICCAVR, CVAVR

Device Support
- USB AVRISP XPII supports all AVR devices with ISP and PDI Interface. Support for new devices will be added with new versions of AVR Studio.
- Supports AT86RF401/AT89S51/AT89S52

Features Overig
  • Supports all AVR devices with ISP or PDI interface, and certain 51 Devices
  • Programs both Flash and EEPROM
  • Supports Fuses and Lock Bit Programming
  • Based on AT AVRISP mkII firmware
  • Upgradable to Support Future Devices
  • Adjustable ISP programming speed up to 8M frequency
  • USB 2.0 compliant (full speed, 12Mbps)
  • 3 optional cables to target board
  • Powered from USB bus, does not require external power supply
Standaard Meegeleverd
  1. USB AVRISP XPII x1
  2. USB Cable x1
  3. 6-pin cable (spare) x1
  4. 6-pin to 10-pin ISP cable x1
  5. 6-wire multicolour custom connector cable x1
  6. User Guide CD x1
  7. Quick start sheet x1
Short Description

USB AVRISP XPII, AVR Programmer
